| Mobilinternet |
5G(SA/NSA), 4G/LTE (Cat 20) |
| WiFi |
802.11 b/g/n/ac Wave 2 (WiFi 5) + 802.11s + 802.11r |
| Ethernet |
5 x 10/100/1000 Mbps |
| SIM |
2 x SIM foglalat |
| MOBILE |
|
| Mobile module |
5G Sub-6Ghz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2); 4G (LTE) – LTE Cat 20 2.0Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL |
| Status |
Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP Bytes sent/received, connected band, IMSI, ICCID. |
| SMS/Call |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, Call utilities: |
| USSD |
Supports sending and reading Unstructured Supplementary Service Data messages |
| Black/White list |
Operator black/white list |
| Band management |
Band lock, Used band status display |
| APN |
Auto APN |
| Bridge mode |
Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough |
Gateway assigns its mobile WAN IP address to another device on LAN |
| Multiple PDN |
Possibility to use different PDNs for multiple network access and services |
| WIRELESS |
|
| Wireless mode |
802.11b/g/n/ac Wave 2 (WiFi 5) with data transmission rates of up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA) |
| WiFi security |
WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation |
| ESSID |
ESSID stealth mode |
| WiFi users |
Up to 150 simultaneous connections |
| Wireless Hotspot |
Captive portal (Hotspot), internal/external Radius server, built-in customizable landing page |
| Wireless mesh/roaming |
Wireless mesh (802.11s), fast roaming (802.11r) |
| ETHERNET |
|
| WAN |
1 x WAN port (can be configured as LAN) 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
| LAN |
4 x RJ45 port, 10/100/1000 Mbps, supports auto MDI/MDIX crossover |
| NETWORK |
|
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL) |
| Routing |
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP) |
| Connection monitoring |
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
| Firewall |
Port forwards, traffic rules, custom rules |
| DHCP |
Static and dynamic IP allocation |
| DDNS |
Supported >25 service providers, others can be configured manually |
| SSHFS |
Possibility to mount remote file system via SSH protocol |
| SECURITY |
|
| Authentication |
Pre-shared key, digital certificates, X.509 certificates |
| Firewall |
Pre-configured firewall rules can be enabled via the WebUI, unlimited firewall configuration via CLI; NAT; NAT-T |
| Attack prevention |
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention ( SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VLAN |
Port and tag-based VLAN separation |
| Mobile quota control |
Set up custom data limits for SIM card |
| WEB filter |
Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
| Access control |
Flexible access control of TCP, UDP, ICMP packets, MAC address filter |
| VPN |
|
| OpenVPN |
Multiple clients and a server can run simultaneously, 12 encryption methods |
| OpenVPN Encryption |
DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC |
| GRE |
GRE tunnel |
| IPsec |
IKEv1, IKEv2, supports up to 5 x VPN IPsec tunnels (instances), with 5 encryption methods (DES, 3DES, AES128, AES192, AES256) |
| SSTP |
SSTP client instance support |
| STUNNEL |
Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code |
| DMVPN |
Method of building scalable IPsec VPNs |
| PPTP, L2TP |
Client/Server services can run simultaneously, L2TPv3 support |
| WireGuard |
WireGuard VPN client and server support |
| ZeroTier |
ZeroTier VPN |
| MODBUS TCP SLAVE |
|
| ID filtering |
Respond to one ID in range [1;255] or any |
| Allow remote access |
Allow access through WAN |
| Custom registers |
MODBUS TCP custom register block, which allows to read/write to a file inside the router, and can be used to extend MODBUS TCP slave functionality |
| MODBUS TCP MASTER |
|
| Supported functions |
01, 02, 03, 04, 05, 06, 15, 16 |
| Supported data formats |
8 bit; INT, UINT; 16 bit; INT, UINT (MSB or LSB first); 32 bit; float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII |
| MQTT GATEWAY |
|
| Gateway |
Allows sending commands and receiving data from MODBUS Master through the MQTT broker |
| DNP3 |
|
| Supported modes |
TCP Master, DNP3 Outstation |
| DATA TO SERVER |
|
| Protocols |
HTTP(S), MQTT, Azure MQTT, Kinesis |
| IoT PLATFORMS |
|
| Clouds of things |
Allows monitoring of:Device data, Mobile data, Network info, Availability |
| ThingWorx |
Allows monitoring of:WAN Type, WAN IP Mobile Operator Name, Mobile Signal Strength, Mobile Network Type |
| Cumulocity |
Allows monitoring of:Device Model, Revision and Serial Number, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength, WAN Type and IP |
| Azure IoT Hub |
Can send device IP, Number of bytes send/received/ 3G connection state, Network link state, IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, Sim State, PIN state, GSM signal, WCDMA RSCP, WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID, Operator, Operator number, Connection type, Temperature, PIN count to Azure IoT Hub server |
| MONITORING & MANAGEMENT |
|
| WEB UI |
HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log |
| FOTA |
Firmware update from server, automatic notification |
| SSH |
SSH (v1, v2) |
| SMS |
SMS status, SMS configuration, send/read SMS via HTTP POST/GET |
| CALL |
Reboot, Status, Mobile data on/off, Output on/off |
| TR-069 |
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem |
| MQTT |
MQTT Broker, MQTT publisher |
| SNMP |
SNMP (v1, v2, v3), SNMP trap |
| JSON-RPC |
Management API over HTTP/HTTPS |
| MODBUS |
MODBUS TCP status/control |
| RMS |
Teltonika Remote Management System (RMS) |
| SYSTEM CHARACTERISTICS |
|
| CPU |
Quad-core ARM Cortex A7, 717 MHz |
| RAM |
256 MB (100 MB available for userspace) |
| FLASH storage |
256 MB (80 MB available for userspace) |
| FIRMWARE / CONFIGURATION |
|
| WEB UI |
Update FW from file, check FW on server, configuration profiles, configuration backup |
| FOTA |
Update FW |
| RMS |
Update FW/configuration for multiple devices at once |
| Keep settings |
Update FW without losing current configuration |
| FIRMWARE CUSTOMIZATION |
|
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Supported languages |
Busybox shell, Lua, C, C++ |
| Development tools |
SDK package with build environment provided |
| LOCATION TRACKING |
|
| GNSS |
GPS, GLONASS, BeiDou, Galileo and QZSS |
| Coordinates |
GNSS coordinates via WebUI, SMS, TAVL, RMS |
| NMEA |
NMEA 0183 |
| Server software |
Supports server software:TAVL, RMS |
| Geofencing |
Multiple configurable geofence zones |
| USB |
|
| Data rate |
USB 2.0 |
| Applications |
Samba share, USB-to-serial, Modbus gateway |
| External devices |
Possibility to connect external HDD, flash drive, additional modem, printer |
| Storage formats |
FAT, FAT32, NTFS |
| INPUT/OUTPUT |
|
| Input |
1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high |
| Output |
1 x Digital Output, Open collector output, max output 30 V, 300 mA |
| Events |
SMS, Email, RMS |
| I/O juggler |
Allows setting certain I/O conditions to initiate event |
| POWER |
|
| Connector |
4-pin industrial DC power socket |
| Input voltage range |
9 – 50 VDC, reverse polarity protection, surge protection >51 VDC 10us max |
| PoE (passive) |
Mode B, LAN1 Port, 9 - 50 VDC |
| Power consumption |
Idle; <4 W, Max; <18 W |
| PHYSICAL INTERFACES (PORTS, LEDS, ANTENNAS, BUTTONS, SIM) |
|
| Ethernet |
5 x RJ45 ports, 10/100/1000 Mbps |
| I/Os |
1 x Digital Input, 1 x Digital Output on 4-pin power connector |
| Status LEDs |
3 x connection status LEDs, 3 x connection strength LEDs, 10 x Ethernet port status LEDs, 4 x WAN status LEDs, 1x Power LED, 2 x 2.4G and 5G WiFi LEDs |
| SIM |
2 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V |
| Power |
1 x 4-pin DC power connector |
| Antennas |
4 x SMA for Mobile, 2 x RP-SMA for WiFi, 1 x SMA for GNSS |
| USB |
1 x USB A port for external devices |
| Reset |
Reboot/User default reset/Factory reset button |
| Other |
1 x Grounding screw |
| PHYSICAL SPECIFICATION |
|
| Casing material |
Aluminum housing |
| Dimensions (W x H x D) |
132 x 44.2 x 95.1 mm |
| Weight |
533 g |
| Mounting options |
DIN rail (can be mounted on two sides), flat surface placement |
| OPERATING ENVIRONMENT |
|
| Operating temperature |
-40 °C to 75 °C |
